WPFGrid布局

WPF中Grid布局XMAl
<Window x:Class="wpfyonghukongjian.login"

        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"

        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"

        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"

        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"

        xmlns:local="clr-namespace:wpfyonghukongjian"

        mc:Ignorable="d"

        Title="login" Height="150" Width="300">

    <Grid>



        <Grid.ColumnDefinitions>

            <ColumnDefinition Width="Auto"/>

            <ColumnDefinition Width="100*"/>

        Grid.ColumnDefinitions>



        <Grid.RowDefinitions>

            <RowDefinition Height="25"/>

            <RowDefinition Height="25"/>

            <RowDefinition Height="25"/>

            <RowDefinition Height="25"/>

        Grid.RowDefinitions>

        <TextBlock Grid.Row="0" Grid.Column="0" TextAlignment="Right" Text="用户名：" Name="UserName" />



        <TextBlock Grid.Row="1" Grid.Column="0" TextAlignment="Right" Text="密码：" Name="pass"/>

        <TextBlock Grid.Row="2" Grid.Column="0" TextAlignment="Right" Text="确认密码：" Name="repass"/>

        <Button Grid.Row="3" Grid.ColumnSpan="2" Height="23" Width="100" Content="确认" Click="Button_Click" Name="btn"/>



        <TextBox Name="TxtBoxName" Grid.Row="0" Grid.Column="1" Text=""  Width="200"/>



        <PasswordBox Name="pass1" Grid.Row="1" Grid.Column="1" Width="200"/>



        <PasswordBox Name="pass2" Grid.Row="2" Grid.Column="1"  Width="200"/>

    Grid>

Window>

效果如图所示
