Qt实现图形裁减

本文实例为大家分享了Qt实现图形裁减的具体代码，供大家参考，具体内容如下

main.cpp

#include
#include
#include
#include
#include

class GraphicsItemGroup : public QGraphicsItemGroup
{
public:
    GraphicsItemGroup(QGraphicsItem *parent = 0) : QGraphicsItemGroup(parent)
    {
        setFlag(QGraphicsItem::ItemClipsChildrenToShape, true);
    }
    QPainterPath shape() const
    {
        if (mShape.isEmpty())
            return QGraphicsItemGroup::shape();
        return mShape;
    }
    void setShape(const QPainterPath &shape)
    {
        mShape = shape;
        update();
    }

private:
    QPainterPath mShape;
};

int main(int argc, char *argv[])
{
    QApplication a(argc, argv);
    QWidget w;
    w.setLayout(new QVBoxLayout);

    QGraphicsView view;
    QPushButton button("click me");

    w.layout()->addWidget(&view);
    w.layout()->addWidget(&button);

    view.setScene(new QGraphicsScene);
    GraphicsItemGroup group;
    view.scene()->addItem(&group);
    auto ellipse = new QGraphicsEllipseItem(QRectF(0, 0, 100, 100));
    ellipse->setBrush(Qt::red);
    auto rect = new QGraphicsRectItem(QRect(150, 150, 100, 100));
    rect->setBrush(Qt::blue);
    group.addToGroup(ellipse);
    group.addToGroup(rect);

    QObject::connect(&button, &QPushButton::clicked, [&group]()
    {
        QPainterPath shape;
        if (group.shape().boundingRect() == group.boundingRect())
        {
            shape.addRect(0, 50, 250, 150);
        }
        group.setShape(shape);
    });

    w.show();
    return a.exec();
}

以上就是本文的全部内容，希望对大家的学习有所帮助，也希望大家多多支持脚本之家。
