在springboot加vue项目中加入图形验证码

后端

首先先要创建一个CaptchaController的类，可以在下面的代码中看到

在getCaptcha的方法里面写好了生成随机的4位小写字母或数字的验证码，然后通过BufferedImage类变为图片，顺便加上了干扰线。之后把图片转为Base64编码方便传给前端

为了安全我写了encrypt方法把4位验证码加密了一下，和图片放在了Mapli传给了前端，后面的verifyCaptcha是对前端输入的内容和我们生成的验证码进行比较，并返回状态码。

package cn.kmbeast.controller;

import org.apache.commons.lang3.RandomStringUtils;
import org.springframework.web.bind.annotation.CrossOrigin;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PostMapping;
import org.springframework.web.bind.annotation.RequestBody;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

import javax.crypto.Cipher;
import javax.crypto.spec.SecretKeySpec;
import javax.imageio.ImageIO;
import javax.servlet.http.HttpServletResponse;
import java.awt.*;
import java.awt.image.BufferedImage;
import java.io.IOException;
import java.util.Base64;
import java.util.HashMap;
import java.util.Map;

@RestController
@RequestMapping("/captcha")
public class CaptchaController {

    private static final String ALGORITHM = "AES";
    private static final String SECRET_KEY = "1234567890123456"; // 16字节的密钥

    @GetMapping("/get")
    public Map getCaptcha(HttpServletResponse response) throws Exception {
        System.out.println("验证码已生成");
        response.setContentType("image/png");
        response.setHeader("Cache-Control", "no-cache");
        response.setHeader("Expires", "0");

        // 生成随机4位验证码（字母+数字）
        String code = RandomStringUtils.randomAlphanumeric(4).toLowerCase();

        // 加密验证码
        String encryptedCode = encrypt(code);

        // 生成图片
        int width = 100, height = 40;
        BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_RGB);
        Graphics2D g = image.createGraphics();

        // 设置背景
        g.setColor(Color.WHITE);
        g.fillRect(0, 0, width, height);

        // 绘制干扰线
        g.setColor(Color.GRAY);
        for (int i = 0; i < 10; i++) {
            int x1 = (int) (Math.random() * width);
            int y1 = (int) (Math.random() * height);
            int x2 = (int) (Math.random() * width);
            int y2 = (int) (Math.random() * height);
            g.drawLine(x1, y1, x2, y2);
        }

        // 绘制验证码
        g.setColor(Color.BLACK);
        g.setFont(new Font("Arial", Font.BOLD, 30));
        g.drawString(code, 15, 30);
        g.dispose();

        // 将图片转换为Base64编码
        java.io.ByteArrayOutputStream baos = new java.io.ByteArrayOutputStream();
        ImageIO.write(image, "PNG", baos);
        byte[] imageBytes = baos.toByteArray();
        String base64Image = Base64.getEncoder().encodeToString(imageBytes);

        Map result = new HashMap<>();
        result.put("image", base64Image);
        result.put("encryptedCode", encryptedCode);
        return result;
    }

    @PostMapping("/verify")
    public Map verifyCaptcha(@RequestBody Map requestBody) {
        Map result = new HashMap<>();
        String inputCode = requestBody.get("code");
        String encryptedCode = requestBody.get("encryptedCode");

        try {
            // 解密验证码
            String decryptedCode = decrypt(encryptedCode);
            if (!decryptedCode.equalsIgnoreCase(inputCode)) {
                result.put("code", 500);
                result.put("msg", "验证码错误");
            } else {
                result.put("code", 200);
                result.put("msg", "验证码验证通过");
            }
        } catch (Exception e) {
            result.put("code", 500);
            result.put("msg", "验证码验证出错");
        }
        return result;
    }

    // 加密方法
    private String encrypt(String data) throws Exception {
        SecretKeySpec secretKey = new SecretKeySpec(SECRET_KEY.getBytes(), ALGORITHM);
        Cipher cipher = Cipher.getInstance(ALGORITHM);
        cipher.init(Cipher.ENCRYPT_MODE, secretKey);
        byte[] encryptedBytes = cipher.doFinal(data.getBytes());
        return Base64.getEncoder().encodeToString(encryptedBytes);
    }

    // 解密方法
    private String decrypt(String encryptedData) throws Exception {
        SecretKeySpec secretKey = new SecretKeySpec(SECRET_KEY.getBytes(), ALGORITHM);
        Cipher cipher = Cipher.getInstance(ALGORITHM);
        cipher.init(Cipher.DECRYPT_MODE, secretKey);
        byte[] decryptedBytes = cipher.doFinal(Base64.getDecoder().decode(encryptedData));
        return new String(decryptedBytes);
    }
}

前端

在网页要渲染的样式

逻辑处理

//在data里加入
data() {
        return {
            captchaImage: '', // 新增：用于存储验证码图片的 Base64 编码
            encryptedCode: '' // 新增：用于存储加密的验证码
        }
    },methods: {

 // 刷新验证码
        async refreshCaptcha() {
            try {
                const { data } = await request.get(`http://localhost:8088/api/online-travel-sys/v1.0/captcha/get`);
                this.encryptedCode = data.encryptedCode;
                this.code = ''; // 刷新验证码时清空输入框
            } catch (error) {
                console.error('获取验证码出错:', error);
            }
        },
        async login() {
            if (!this.act || !this.pwd) {
                this.$swal.fire({
                    title: '填写校验',
                    text: '账号或密码不能为空',
                    icon: 'error',
                    showConfirmButton: false,
                    timer: DELAY_TIME,
                });
                return;
            }
            if (!this.code) {
                this.$swal.fire({
                    title: '填写校验',
                    text: '验证码不能为空',
                    icon: 'error',
                    showConfirmButton: false,
                    timer: DELAY_TIME,
                });
                return;
            }
            // 先验证验证码是否正确
            try {
                const { data } = await request.post(`http://localhost:8088/api/online-travel-sys/v1.0/captcha/verify`, { code: this.code, encryptedCode: this.encryptedCode });
                if (data.code !== 200) {
                    this.$swal.fire({
                        title: '验证码错误',
                        text: data.msg,
                        icon: 'error',
                        showConfirmButton: false,
                        timer: DELAY_TIME,
                    });
                    this.refreshCaptcha(); // 刷新验证码
                    return;
                }
            } catch (error) {
                console.error('验证码验证请求错误:', error);
                this.$message.error('验证码验证出错，请重试！');
                this.refreshCaptcha(); // 刷新验证码
                return;
            }

}

完整的前端代码

结果展示
