深度学习笔记 - 104 - 用Numpy构建神经网络


Code

from numpy import exp, array, random, dot


class NeuralNetwork():
    def __init__(self):
        # Seed the random number generator, so it generates the same numbers
        # every time the program runs.
        random.seed(1)

        # We model a single neuron, with 3 input connections and 1 output connection.
        # We assign random weights to a 3 x 1 matrix, with values in the range -1 to 1
        # and mean 0.
        self.synaptic_weights = 2 * random.random((3, 1)) - 1

    # The Sigmoid function, which describes an S shaped curve.
    # We pass the weighted sum of the inputs through this function to
    # normalise them between 0 and 1.
    def __sigmoid(self, x):
        return 1 / (1 + exp(-x))

    # The derivative of the Sigmoid function.
    # This is the gradient of the Sigmoid curve.
    # It indicates how confident we are about the existing weight.
    def __sigmoid_derivative(self, x):
        return x * (1 - x)

    # We train the neural network through a process of trial and error.
    # Adjusting the synaptic weights each time.
    def train(self, training_set_inputs, training_set_outputs, number_of_training_iterations):
        for iteration in xrange(number_of_training_iterations):
            # Pass the training set through our neural network (a single neuron).
            output = self.think(training_set_inputs)

            # Calculate the error (The difference between the desired output
            # and the predicted output).
            error = training_set_outputs - output

            # Multiply the error by the input and again by the gradient of the Sigmoid curve.
            # This means less confident weights are adjusted more.
            # This means inputs, which are zero, do not cause changes to the weights.
            adjustment = dot(training_set_inputs.T, error * self.__sigmoid_derivative(output))

            # Adjust the weights.
            self.synaptic_weights += adjustment

    # The neural network thinks.
    def think(self, inputs):
        # Pass inputs through our neural network (our single neuron).
        return self.__sigmoid(dot(inputs, self.synaptic_weights))


if __name__ == "__main__":

    #Intialise a single neuron neural network.
    neural_network = NeuralNetwork()

    print "Random starting synaptic weights: "
    print neural_network.synaptic_weights

    # The training set. We have 4 examples, each consisting of 3 input values
    # and 1 output value.
    training_set_inputs = array([[0, 0, 1], [1, 1, 1], [1, 0, 1], [0, 1, 1]])
    training_set_outputs = array([[0, 1, 1, 0]]).T

    # Train the neural network using a training set.
    # Do it 10,000 times and make small adjustments each time.
    neural_network.train(training_set_inputs, training_set_outputs, 10000)

    print "New synaptic weights after training: "
    print neural_network.synaptic_weights

    # Test the neural network with a new situation.
    print "Considering new situation [1, 0, 0] -> ?: "
    print neural_network.think(array([1, 0, 0]))

Results

C:\Anaconda3\envs\python2\python.exe D:/Workspace/TensorFlow_LIB/siraj-regression.py
Random starting synaptic weights:
[[-0.16595599]
 [ 0.44064899]
 [-0.99977125]]
New synaptic weights after training:
[[ 9.67299303]
 [-0.2078435 ]
 [-4.62963669]]
Considering new situation [1, 0, 0] -> ?:
[ 0.99993704]

Process finished with exit code 0

Breaking it Down

1. A Neural Network is an algorithm that learns to identify patterns in data

2. Backpropagation is a technique to train a Neural Net by updating weights via gradient descent

3. Deep Learning = many layer neural net + big data + big compute
