#!/usr/bin/env python # -*- coding: utf-8 -*- import pygtk pygtk.require('2.0') import gtk class RulersExample: XSIZE = 400 YSIZE = 400 xpos=0.0 ypos=0.0 # This routine gets control when the close button is clicked def close_application(self, widget, event, data=None): gtk.main_quit() return False def __init__(self): window = gtk.Window(gtk.WINDOW_TOPLEVEL) window.connect("delete_event", self.close_application) window.set_border_width(10) # Create a table for placing the ruler and the drawing area table = gtk.Table(3, 2, False) window.add(table) area = gtk.DrawingArea() area.set_size_request(self.XSIZE, self.YSIZE) table.attach(area, 1, 2, 1, 2, gtk.EXPAND|gtk.FILL, gtk.FILL, 0, 0 ) area.set_events(gtk.gdk.POINTER_MOTION_MASK | gtk.gdk.POINTER_MOTION_HINT_MASK ) def vmotion_notify(ruler, event): self.ypos=ruler.get_range()[2] print "(%f,%f)"%(self.xpos,self.ypos) return ruler.emit("motion_notify_event", event) def hmotion_notify(ruler, event): self.xpos=ruler.get_range()[2] print "(%f,%f)"%(self.xpos,self.ypos) return ruler.emit("motion_notify_event", event) # The horizontal ruler goes on top. As the mouse moves across the # drawing area, a motion_notify_event is passed to the # appropriate event handler for the ruler. hrule = gtk.HRuler() hrule.set_metric(gtk.PIXELS) hrule.set_range(7, 13, 0, 20) #当mouse指针在前面定义的drawingarea移动时,motion_notify_event信号 被关联到motion_notify处理器 #通常对象为widget时,connect_object()允许处理仅使用一个参数或2个参数的回调函数 area.connect_object("motion_notify_event", hmotion_notify, hrule) table.attach(hrule, 1, 2, 0, 1, gtk.EXPAND|gtk.SHRINK|gtk.FILL, gtk.FILL, 0, 0 ) # The vertical ruler goes on the left. As the mouse moves across # the drawing area, a motion_notify_event is passed to the # appropriate event handler for the ruler. vrule = gtk.VRuler() vrule.set_metric(gtk.PIXELS) vrule.set_range(0, self.YSIZE, 10, self.YSIZE) area.connect_object("motion_notify_event", vmotion_notify, vrule) table.attach(vrule, 0, 1, 1, 2, gtk.FILL, gtk.EXPAND|gtk.SHRINK|gtk.FILL, 0, 0 ) # Now show everything area.show() hrule.show() vrule.show() table.show() window.show() def main(): gtk.main() return 0 if __name__ == "__main__": RulersExample() main()
