第二人生的源码分析(二十一)显示人物名称的字体

前面已经介绍了显示人物名称的基本框架，但是使用OpenGL显示这个名称出来是需要很复杂的步骤。由于OpenGL是图形引擎显示，也就是说所有字符的显示都是基于图形来显示，而图形的显示，就需要获取字体的图片，即是获取字体的字模。由于不能使用Windows的标准GDI来显示，那么就需要实现GDI所做的所有功能，比如从字体里读取每个字符的轮廓，然后生成合适大小的位图，再把这幅位图当作纹理贴到3D的平面上去，这样才可以在OpenGL显示字符串出来。在第二人生里的代码流程如下：

1、LLFontGL::addChar()     添加一个字符纹理图片

2、mImageGLp->bind()        绑定纹理图片。

3、LLImageGL::bindTextureInternal()       真正绑定纹理图片，在这个函数里调用glBindTexture函数来绑定纹理。

4、LLFontGL::render()             这个函数显示所有字符串。

仔细地分析一下这个函数，看看怎么样显示字符串的，如下：

#001 S32 LLFontGL::render(const LLWString &wstr,

#002                                    const S32 begin_offset,

#003                                    const F32 x, const F32 y,

#004                                    const LLColor4 &color,

#005                                    const HAlign halign, const VAlign valign,

#006                                    U8 style,

#007                                    const S32 max_chars, S32 max_pixels,

#008                                    F32* right_x,

#009                                    BOOL use_embedded,

#010                                    BOOL use_ellipses) const

#011 {

#012       LLGLEnable texture_2d(GL_TEXTURE_2D);

#013



下面绑定纹理图片。

#089

#090       // Bind the font texture

#091

#092       mImageGLp->bind(0);

#093

#094       glBlendFunc(GL_SRC_ALPHA, GL_ONE_MINUS_SRC_ALPHA); // Not guaranteed to be set correctly

#095



下面开始循环地显示字符串。

#160

#161       for (i = begin_offset; i < begin_offset + length; i++)

#162       {

#163              llwchar wch = wstr[i];

#164

#165              // Handle embedded characters first, if they're enabled.

#166              // Embedded characters are a hack for notecards

#167              const embedded_data_t* ext_data = use_embedded ? getEmbeddedCharData(wch) : NULL;

#168              if (ext_data)

#169              {

……



#224                     // Bind the font texture

#225                     mImageGLp->bind();

#226              }

#227              else

#228              {

#229                     if (!hasGlyph(wch))

#230                     {

#231                            (const_cast<LLFontGL*>(this))->addChar(wch);

#232                     }

#233

#234                     const LLFontGlyphInfo* fgi= getGlyphInfo(wch);

#235                     if (!fgi)

#236                     {

#237                            llerrs << "Missing Glyph Info" << llendl;

#238                            break;

#239                     }

#240                     if ((start_x + scaled_max_pixels) < (cur_x + fgi->mXBearing + fgi->mWidth))

#241                     {

#242                            // Not enough room for this character.

#243                            break;

#244                     }

#245

#246                     // Draw the text at the appropriate location

#247                     //Specify vertices and texture coordinates

#248                     LLRectf uv_rect((fgi->mXBitmapOffset - PAD_AMT) * inv_width,

#249                                                 (fgi->mYBitmapOffset + fgi->mHeight + PAD_AMT) * inv_height,

#250                                                 (fgi->mXBitmapOffset + fgi->mWidth + PAD_AMT) * inv_width,

#251                                                 (fgi->mYBitmapOffset - PAD_AMT) * inv_height);

#252                     LLRectf screen_rect(cur_render_x + (F32)fgi->mXBearing - PAD_AMT,

#253                                                        cur_render_y + (F32)fgi->mYBearing + PAD_AMT,

#254                                                        cur_render_x + (F32)fgi->mXBearing + (F32)fgi-

#255 >mWidth + PAD_AMT,

#256                                                        cur_render_y + (F32)fgi->mYBearing - (F32)fgi-

#257 >mHeight - PAD_AMT);

#258



这里设置每个字符的纹理坐标以及顶点坐标。

# 259                    drawGlyph(screen_rect, uv_rect, color, style, drop_shadow_strength);

#260

#261                     chars_drawn++;

#262                     cur_x += fgi->mXAdvance;

#263                     cur_y += fgi->mYAdvance;

#264

#265                     llwchar next_char = wstr[i+1];

#266                     if (next_char && (next_char < LAST_CHARACTER))

#267                     {

#268                            // Kern this puppy.

#269                            if (!hasGlyph(next_char))

#270                            {

#271                                   (const_cast<LLFontGL*>(this))->addChar(next_char);

#272                            }

#273                            cur_x += getXKerning(wch, next_char);

#274                     }

#275

#276                     // Round after kerning.

#277                     // Must do this to cur_x, not just to cur_render_x, otherwise you

#278                     // will squish sub-pixel kerned characters too close together.

#279                     // For example, "CCCCC" looks bad.

#280                     cur_x = (F32)llfloor(cur_x + 0.5f);

#281                     //cur_y = (F32)llfloor(cur_y + 0.5f);

#282

#283                     cur_render_x = cur_x;

#284                     cur_render_y = cur_y;

#285              }

#286       }

#287

……



#320              glPopMatrix();

#321       }

#322

#323       glPopMatrix();

#324

#325       return chars_drawn;

#326 }

#327



蔡军生  2008/01/25 QQ:9073204 深圳
