Unity3D研究院之FBX模型的载入与人物行走动画的播放

 3D 世界中自定义模型的使用恐怕是重中之重，因为系统自身提供的模型肯定是无法满足GD对游戏的策划，所以为了让游戏更加绚丽，我们须要调用美术制作的精品模型与动画，本章MOMO将带领盆友们学习Unity3D中模型的载入与动画的播放，哇咔咔～～

       由于MOMO手头上没有现成的模型，所以我将在Unity3D 官网中下载官方提供的游戏DEMO 中的模型来使用。另外官方提供了很多Unity3D 游戏DEMO,与详细的文档。可以帮助我们学习Unity.有兴趣的盆友可以去看看哈。

下载页面：http://unity3d.com/support/resources/

本章博文的目的是利用上一章介绍的游戏摇杆来控制人物模型的移动，与行走动画的播放。





如上图所示Create中的文件夹male中存放着模型动画与贴图等，这个应该是美术提供给我们的。然后将整个male用鼠标拖动到左侧3D世界中，通过移动，旋转，缩放将人物模型放置在一个理想的位置。右侧红框内设置模型动画的属性。

Animation

        idle1  该模型默认动画名称为idle1

Animations

        size   该模型动画的数量

        Element 该模型的动画名称

Play Automatically 是否自动播放

Animation Physics 是否设置该模型物理碰撞

Animation Only if Visable 是否设置该模型仅自己显示



给该模型绑定一个脚本Controller.cs 用来接收摇杆返回的信息更新模型动画。

Controller.cs

01 using UnityEngine;
02 using System.Collections;
03
04 public class Controller : MonoBehaviour {
05
06     //人物的行走方向状态
07     public const int HERO_UP= 0;
08     public const int HERO_RIGHT= 1;
09     public const int HERO_DOWN= 2;
10     public const int HERO_LEFT= 3;
11
12     //人物当前行走方向状态
13     public int state = 0;
14
15     //备份上一次人物当前行走方向状态
16     //这里暂时没有用到
17     public int backState = 0;
18
19     //游戏摇杆对象
20     public MPJoystick moveJoystick;
21
22     //这个方法只调用一次，在Start方法之前调用
23     public void Awake() {
24
25     }
26
27     //这个方法只调用一次，在Awake方法之后调用
28     void Start () {
29         state = HERO_DOWN;
30     }
31
32     void Update () {
33
34     //获取摇杆控制的方向数据 上一章有详细介绍
35     float touchKey_x =  moveJoystick.position.x;
36     float touchKey_y =  moveJoystick.position.y;
37
38     if(touchKey_x == -1){
39        setHeroState(HERO_LEFT);
40
41     }else if(touchKey_x == 1){
42        setHeroState(HERO_RIGHT);
43
44     }
45
46     if(touchKey_y == -1){
47         setHeroState(HERO_DOWN);
48
49     }else if(touchKey_y == 1){
50         setHeroState(HERO_UP);
51     }
52
53     if(touchKey_x == 0 && touchKey_y ==0){
54         //松开摇杆后播放默认动画，
55         //不穿参数为播放默认动画。
56         animation.Play();
57     }
58
59     }
60
61     public void setHeroState(int newState)
62     {
63
64         //根据当前人物方向 与上一次备份方向计算出模型旋转的角度
65         int rotateValue = (newState - state) * 90;
66         Vector3 transformValue = new Vector3();
67
68         //播放行走动画
69         animation.Play("walk");
70
71         //模型移动的位移的数值
72         switch(newState){
73             case HERO_UP:
74                 transformValue = Vector3.forward * Time.deltaTime;
75             break;
76             case HERO_DOWN:
77                 transformValue = -Vector3.forward * Time.deltaTime;
78             break;
79             case HERO_LEFT:
80                 transformValue = Vector3.left * Time.deltaTime;
81
82             break;
83             case HERO_RIGHT:
84                 transformValue = -Vector3.left * Time.deltaTime;
85             break;
86         }
87
88         //模型旋转
89         transform.Rotate(Vector3.up, rotateValue);
90
91         //模型移动
92         transform.Translate(transformValue, Space.World);
93
94         backState = state;
95         state = newState;
96
97     }
98
99 }



上一章介绍了javaScript脚本使用游戏摇杆的方法，本章MOMO告诉大家使用C＃脚本来使用游戏摇杆，上面我用 Controller.cs  C＃脚本来接收系统提供的Joystick.js是肯定无法使用的，须要修改成.cs文件，我在国外的一个网站上看到了一个老外帮我们已经修改了，那么我将他修改后的代码贴出来方便大家学习，有兴趣的朋友可以研究研究。哇咔咔～

MPJoystick.cs

001 using UnityEngine;
002
003 /**
004
005  * File: MPJoystick.cs
006
007  * Author: Chris Danielson of (monkeyprism.com)
008
009  *
010
011 // USED TO BE: Joystick.js taken from Penelope iPhone Tutorial
012
013 //
014
015 // Joystick creates a movable joystick (via GUITexture) that
016
017 // handles touch input, taps, and phases. Dead zones can control
018
019 // where the joystick input gets picked up and can be normalized.
020
021 //
022
023 // Optionally, you can enable the touchPad property from the editor
024
025 // to treat this Joystick as a TouchPad. A TouchPad allows the finger
026
027 // to touch down at any point and it tracks the movement relatively
028
029 // without moving the graphic
030
031 */
032 [RequireComponent(typeof(GUITexture))]
033
034 public class MPJoystick : MonoBehaviour
035
036 {
037
038 class Boundary {
039
040 public Vector2 min = Vector2.zero;
041
042 public Vector2 max = Vector2.zero;
043
044 }
045 private static MPJoystick[] joysticks;   // A static collection of all joysticks
046
047 private static bool enumeratedJoysticks = false;
048
049 private static float tapTimeDelta = 0.3f;    // Time allowed between taps
050 public bool touchPad;
051
052 public Vector2 position = Vector2.zero;
053
054 public Rect touchZone;
055
056 public Vector2 deadZone = Vector2.zero;  // Control when position is output
057
058 public bool normalize = false; // Normalize output after the dead-zone?
059
060 public int tapCount;
061
062 private int lastFingerId = -1;   // Finger last used for this joystick
063
064 private float tapTimeWindow;     // How much time there is left for a tap to occur
065
066 private Vector2 fingerDownPos;
067
068 //private float fingerDownTime;
069
070 //private float firstDeltaTime = 0.5f;
071 private GUITexture gui;
072
073 private Rect defaultRect;    // Default position / extents of the joystick graphic
074
075 private Boundary guiBoundary = new Boundary();   // Boundary for joystick graphic
076
077 private Vector2 guiTouchOffset;  // Offset to apply to touch input
078
079 private Vector2 guiCenter;   // Center of joystick
080 void Start() {
081
082 gui = (GUITexture)GetComponent(typeof(GUITexture));
083 defaultRect = gui.pixelInset;
084
085 defaultRect.x += transform.position.x * Screen.width;// + gui.pixelInset.x; // -  Screen.width * 0.5;
086
087         defaultRect.y += transform.position.y * Screen.height;// - Screen.height * 0.5;
088 transform.position = Vector3.zero;
089 if (touchPad) {
090
091 // If a texture has been assigned, then use the rect ferom the gui as our touchZone
092
093 if ( gui.texture )
094
095 touchZone = defaultRect;
096
097 } else {
098
099 guiTouchOffset.x = defaultRect.width * 0.5f;
100
101 guiTouchOffset.y = defaultRect.height * 0.5f;
102 // Cache the center of the GUI, since it doesn't change
103
104 guiCenter.x = defaultRect.x + guiTouchOffset.x;
105
106 guiCenter.y = defaultRect.y + guiTouchOffset.y;
107 // Let's build the GUI boundary, so we can clamp joystick movement
108
109 guiBoundary.min.x = defaultRect.x - guiTouchOffset.x;
110
111 guiBoundary.max.x = defaultRect.x + guiTouchOffset.x;
112
113 guiBoundary.min.y = defaultRect.y - guiTouchOffset.y;
114
115 guiBoundary.max.y = defaultRect.y + guiTouchOffset.y;
116
117 }
118
119 }
120 public Vector2 getGUICenter() {
121
122 return guiCenter;
123
124 }
125 void Disable() {
126
127 gameObject.active = false;
128
129 //enumeratedJoysticks = false;
130
131 }
132 private void ResetJoystick() {
133
134 gui.pixelInset = defaultRect;
135
136 lastFingerId = -1;
137
138 position = Vector2.zero;
139
140 fingerDownPos = Vector2.zero;
141
142 }
143 private bool IsFingerDown() {
144
145 return (lastFingerId != -1);
146
147 }
148 public void LatchedFinger(int fingerId) {
149
150 // If another joystick has latched this finger, then we must release it
151
152 if ( lastFingerId == fingerId )
153
154 ResetJoystick();
155
156 }
157 void Update() {
158
159 if (!enumeratedJoysticks) {
160
161 // Collect all joysticks in the game, so we can relay finger latching messages
162
163 joysticks = (MPJoystick[])FindObjectsOfType(typeof(MPJoystick));
164
165 enumeratedJoysticks = true;
166
167 }
168 int count = Input.touchCount;
169 if ( tapTimeWindow > 0 )
170
171 tapTimeWindow -= Time.deltaTime;
172
173 else
174
175 tapCount = 0;
176 if ( count == 0 )
177
178 ResetJoystick();
179
180 else
181
182 {
183
184 for(int i = 0; i < count; i++) {
185
186 Touch touch = Input.GetTouch(i);
187
188 Vector2 guiTouchPos = touch.position - guiTouchOffset;
189 bool shouldLatchFinger = false;
190
191 if (touchPad) {
192
193 if (touchZone.Contains(touch.position))
194
195 shouldLatchFinger = true;
196
197 }
198
199 else if (gui.HitTest(touch.position)) {
200
201 shouldLatchFinger = true;
202
203 }
204 // Latch the finger if this is a new touch
205
206 if (shouldLatchFinger && (lastFingerId == -1 ¦¦ lastFingerId != touch.fingerId )) {
207 if (touchPad) {
208
209 //gui.color.a = 0.15;
210
211 lastFingerId = touch.fingerId;
212
