vtk实战(二十四)——读入vtu数据

主要采用vtkXMLUnstructuredGridReader()类读取非结构化网格结构的vtk XML格式的文件。

#include <vtkXMLUnstructuredGridReader.h>
#include <vtkSmartPointer.h>
#include <vtkDataSetMapper.h>
#include <vtkActor.h>
#include <vtkRenderWindow.h>
#include <vtkRenderer.h>
#include <vtkRenderWindowInteractor.h>

int main()
{
    std::string filename = "quadraticTetra01.vtu";

    vtkSmartPointer<vtkXMLUnstructuredGridReader> reader =      vtkSmartPointer<vtkXMLUnstructuredGridReader>::New();
    reader->SetFileName(filename.c_str());
    reader->Update();

    vtkSmartPointer<vtkDataSetMapper> mapper =
        vtkSmartPointer<vtkDataSetMapper>::New();
    mapper->SetInputConnection(reader->GetOutputPort());

    vtkSmartPointer<vtkActor> actor =
        vtkSmartPointer<vtkActor>::New();
    actor->SetMapper(mapper);

    vtkSmartPointer<vtkRenderer> renderer =vtkSmartPointer<vtkRenderer>::New();
    vtkSmartPointer<vtkRenderWindow> renderWindow =vtkSmartPointer<vtkRenderWindow>::New();
    renderWindow->AddRenderer(renderer);
    vtkSmartPointer<vtkRenderWindowInteractor> renderWindowInteractor =vtkSmartPointer<vtkRenderWindowInteractor>::New();
    renderWindowInteractor->SetRenderWindow(renderWindow);
    renderer->AddActor(actor);
    renderer->SetBackground(.3, .6, .3);
    renderWindow->Render();
    renderWindowInteractor->Start();

    return 0;
}

代码链接：
