(五) Nepxion分布式RPC框架 - 通信协议框架

Nepxion Thunder（QQ 1394997）发布在淘宝代码基地 http://code.taobao.org/p/Thunder/



•  1 ServerExecutor.java - 服务端运行器接口
         interfaze ：接口名(例如com.nepxion.thunder.test.service.UserService)
         applicationEntity包含四个参数：application(应用名)，group(组名)，host(服务地址)，port(端口)。应用名和组名的作用，一是为了管理方便，二是防止同名接口的出现
         ServerExecutor.java作用是根据接口名+应用名+组名+服务地址+端口发布一个服务


  public interface ServerExecutor extends ThunderDelegate {
      // 服务端启动
      void start(String interfaze, ApplicationEntity applicationEntity) throws Exception;

      // 服务端是否启动
      boolean started(String interfaze, ApplicationEntity applicationEntity) throws Exception;
  }

• 2 AbstractServerExecutor.java - ServerExecutor.java的抽象实现，具体逻辑到各个通信中间件的去实现
• 3 ServerHandlerAdapter.java - 服务端处理逻辑的封装适配，分为三部分：处理结果(安全访问的拦截)，处理异常，处理监控。服务端的处理是异步多线程


  public class ServerHandlerAdapter extends ThunderDelegateImpl {
      private static final Logger LOG = LoggerFactory.getLogger(ServerHandlerAdapter.class);

      public void handle(ProtocolRequest request, ProtocolResponse response) throws Exception {
          if (LOG.isDebugEnabled()) {
              LOG.debug("Request={}", JsonUtil.toJson(request));
          }

          try {
              handleResult(request, response);
          } catch (Exception e) {
              handleException(e, response);
              throw e;
          } finally {
              handleMonitor(request);
          }
      }

      private void handleResult(ProtocolRequest request, ProtocolResponse response) throws Exception {
          boolean heartbeat = request.isHeartbeat();
          if (heartbeat) {
              LOG.info("Receive heart beat request...");

              return;
          }

          String messageId = request.getMessageId();
          String interfaze = request.getInterface();
          boolean async = request.isAsync();
          long timeout = request.getTimeout();
          boolean broadcast = request.isBroadcast();
          MethodKey methodKey = request.createMethodKey();

          response.setMessageId(messageId);
          response.setInterface(interfaze);
          response.setAsync(async);
          response.setTimeout(timeout);
          response.setBroadcast(broadcast);
          response.setHeartbeat(heartbeat);
          response.setMethodKey(methodKey);

          SecurityExecutor securityExecutor = executorContainer.getSecurityExecutor();
          if (securityExecutor != null) {
              boolean authorized = securityExecutor.process(request, response);
              if (!authorized) {
                  return;
              }
          }

          Map<String, ServiceEntity> serviceEntityMap = cacheContainer.getServiceEntityMap();
          ServiceEntity serviceEntity = serviceEntityMap.get(interfaze);

          String methodName = request.getMethod();
          Class<?>[] parameterTypes = request.getParameterTypes();
          Object[] parameters = request.getParameters();

          Object service = serviceEntity.getService();
          Class<?> clazz = service.getClass();
          Method method = clazz.getMethod(methodName, parameterTypes);
          Object result = method.invoke(service, parameters);
          response.setResult(result);
      }

      private void handleException(Exception e, ProtocolResponse response) {
          response.setException(e);
      }

      private void handleMonitor(ProtocolRequest request) throws Exception {
          boolean heartbeat = request.isHeartbeat();
          if (!heartbeat) {
              MonitorExecutor monitorExecutor = executorContainer.getMonitorExecutor();
              if (monitorExecutor != null) {
                  monitorExecutor.process(request);
              }
          }
      }
  }

• 4 ClientExecutor.java - 调用端运行器接口
        ClientExecutor.java作用是根据接口名+应用名+组名+服务地址+端口获取一个服务，对服务上下线后的回调


  public interface ClientExecutor extends ThunderDelegate {

      // 客户端启动连接
      void start(String interfaze, ApplicationEntity applicationEntity) throws Exception;

      // 客户端是否启动
      boolean started(String interfaze, ApplicationEntity applicationEntity) throws Exception;

      // 客户端上线
      void online(String interfaze, ApplicationEntity applicationEntity, Object handler) throws Exception;

      // 客户端下线
      void offline(String interfaze, ApplicationEntity applicationEntity) throws Exception;
  }

• 5 AbstractClientExecutor.java - ClientExecutor.java的抽象实现，具体逻辑到各个通信中间件的去实现
• 6 ClientHandlerAdapter.java - 调用端处理逻辑的封装适配，分为四部分：处理同步/异步返回结果(异步心跳和广播忽略)，处理异常，处理监控。同步模式下，用CyclicBarrier做异步模拟同步等待


  public class ClientHandlerAdapter extends ThunderDelegateImpl {
      private static final Logger LOG = LoggerFactory.getLogger(ClientHandlerAdapter.class);

      public void handle(ProtocolResponse response) throws Exception {
          if (LOG.isDebugEnabled()) {
              LOG.debug("Response={}", JsonUtil.toJson(response));
          }

          try {
              if (response.isAsync()) {
                  handleAsync(response);
              } else {
                  handleSync(response);
              }
          } catch (Exception e) {
              handleException(e, response);
              throw e;
          } finally {
              handleMonitor(response);
          }
      }

      @SuppressWarnings("all")
      protected void handleAsync(ProtocolResponse response) throws Exception {
          boolean heartbeat = response.isHeartbeat();
          boolean broadcast = response.isBroadcast();
          if (heartbeat || broadcast) {
              return;
          }

          String interfaze = response.getInterface();
          MethodKey methodKey = response.getMethodKey();

          Map<String, ReferenceEntity> referenceEntityMap = cacheContainer.getReferenceEntityMap();
          ReferenceEntity referenceEntity = referenceEntityMap.get(interfaze);
          MethodEntity methodEntity = referenceEntity.getMethodEntity(methodKey);

          ThunderCallback callback = methodEntity.getCallback();
          if (callback != null) {
              Object result = response.getResult();
              Exception exception = response.getException();
              callback.call(result, exception);
          }
      }

      private void handleSync(ProtocolResponse response) throws Exception {
          String messageId = response.getMessageId();
          Map<String, ResponseEntity> responseEntityMap = cacheContainer.getResponseEntityMap();
          try {
              ResponseEntity responseEntity = responseEntityMap.get(messageId);
              if (responseEntity != null) {
                  responseEntity.setResult(response.getResult());
                  responseEntity.setException(response.getException());

                  CyclicBarrier barrier = responseEntity.getBarrier();
                  barrier.await();
              } else {
                  LOG.info("Timeout sync response for messageId={}", messageId);
              }
          } finally {
              if (responseEntityMap.get(messageId) != null) {
                  responseEntityMap.remove(messageId);
              }
          }
      }

      private void handleException(Exception e, ProtocolResponse response) {
          e.printStackTrace();
      }

      private void handleMonitor(ProtocolResponse response) throws Exception {
          boolean heartbeat = response.isHeartbeat();
          if (!heartbeat) {
              MonitorExecutor monitorExecutor = executorContainer.getMonitorExecutor();
              if (monitorExecutor != null) {
                  monitorExecutor.process(response);
              }
          }
      }
  }

• 7 ClientInterceptor.java - 调用端代理拦截器
        ClientInterceptor.java作用是提供异步调用，同步调用，广播调用三种方式接口


  public interface ClientInterceptor extends ThunderDelegate, MethodInterceptor {
      // 设置要调用的接口
      void setInterface(String interfaze);

      // 异步调用
      void invokeAsync(ProtocolRequest request) throws Exception;

      // 同步调用
      Object invokeSync(ProtocolRequest request) throws Exception;

      // 广播调用
      void invokeBroadcast(ProtocolRequest request) throws Exception;
  }

• 8 AbstractClientInterceptor.java - 调用端代理拦截器的抽象实现，具体逻辑到各个通信中间件的去实现


  public abstract class AbstractClientInterceptor extends ThunderDelegateImpl implements ClientInterceptor {
      protected String interfaze;

      @Override
      public Object invoke(MethodInvocation invocation) throws Throwable {
          String methodName = invocation.getMethod().getName();
          Class<?>[] parameterTypes = invocation.getMethod().getParameterTypes();
          Object[] arguments = invocation.getArguments();
          Class<?> returnType = invocation.getMethod().getReturnType();

          MethodKey methodKey = MethodKey.create(methodName, parameterTypes);
          Map<String, ReferenceEntity> referenceEntityMap = cacheContainer.getReferenceEntityMap();
          ReferenceEntity referenceEntity = referenceEntityMap.get(interfaze);
          MethodEntity methodEntity = referenceEntity.getMethodEntity(methodKey);

          boolean async = methodEntity.isAsync();
          long timeout = methodEntity.getTimeout();
          boolean broadcast = methodEntity.isBroadcast();
          boolean heartbeat = false;
          boolean feedback = !(broadcast || heartbeat || (async && methodEntity.getCallback() == null));

          ProtocolRequest request = new ProtocolRequest();
          request.setInterface(interfaze);
          request.setMethod(methodName);
          request.setParameterTypes(parameterTypes);
          request.setParameters(arguments);
          request.setAsync(async);
          request.setTimeout(timeout);
          request.setBroadcast(broadcast);
          request.setHeartbeat(heartbeat);
          request.setFeedback(feedback);

          Map<String, ReferenceConfig> referenceConfigMap = cacheContainer.getReferenceConfigMap();
          ReferenceConfig referenceConfig = referenceConfigMap.get(interfaze);
          request.setReferenceConfig(referenceConfig);

          if (request.isAsync()) {
              if (request.isBroadcast()) {
                  invokeBroadcast(request);
              } else {
                  invokeAsync(request);
              }

              return null;
          } else {
              return invokeSync(request);
          }
      }

      @Override
      public void setInterface(String interfaze) {
          this.interfaze = interfaze;
      }
  }

• 9 ClientInterceptorAdapter.java - 调用端代理拦截器的处理逻辑封装适应。主要是同步的处理逻辑，异步不同通信中间件方式不一样，不做封装


  public class ClientInterceptorAdapter extends ThunderDelegateImpl {
      private static final Logger LOG = LoggerFactory.getLogger(ClientInterceptorAdapter.class);

      public Object invokeSync(ClientInterceptor clientInterceptor, ProtocolRequest request) throws Exception {
          ResponseEntity responseEntity = new ResponseEntity();
          CyclicBarrier barrier = new CyclicBarrier(2);
          responseEntity.setBarrier(barrier);

          String messageId = request.getMessageId();
          long timeout = request.getTimeout();
          Map<String, ResponseEntity> responseEntityMap = cacheContainer.getResponseEntityMap();
          responseEntityMap.put(messageId, responseEntity);

          clientInterceptor.invokeAsync(request);

          try {
              // 同步等待返回结果
              try {
                  responseEntity.getBarrier().await(timeout, TimeUnit.MILLISECONDS);
              } catch (Exception e) {
                  LOG.error("Sync method timeout", e);
                  responseEntity.setResult(null);
                  responseEntity.setException(null);
              }

              if (responseEntity.getException() != null) {
                  throw responseEntity.getException();
              }

              return responseEntity.getResult();
          } finally {
              if (responseEntityMap.get(messageId) != null) {
                  responseEntityMap.remove(messageId);
              }
          }
      }
  }

• 10 ProtocolMessage.java - 序列化类


      private String messageId;      // UUID.randomUUID()的随机字符串，作为消息的唯一ID
      private String interfaze;      // 接口名
      private boolean async;         // 异步或者同步请求
      private long timeout;          // 超时时间(只用于同步方法)
      private boolean broadcast;     // 广播模式(广播模式前提必须是异步请求)
      private boolean heartbeat;     // 心跳模式
      private boolean feedback;      // 是否需要服务端反馈结果(只用于异步方法，有一种调用方式，客户端只把请求发送出去，不需要服务端返回）
      private long timestamp;        // 消息创建时间
      private Object requestSource;  // 请求Source(一般是IP:Port格式的字符串)
      private Object responseSource; // 响应Source(一般是(IP:Port格式的字符串)

• 11 ProtocolRequest.java - 调用端发送到服务端的请求类，继承于ProtocolMessage.java，序列化类


      private String method;                   // 方法名
      private Class<?>[] parameterTypes;       // 方法参数的类型
      private Object[] parameters;             // 方法参数的值
      private ReferenceConfig referenceConfig; // 包含secretKey(密钥)，version(版本)

• 12 ProtocolResponse.java - 服务端返回到调用端的响应类，继承于ProtocolMessage.java，序列化类


      private MethodKey methodKey; // 封装方法的相关信息
      private Object result;       // 调用的结果
      private Exception exception; // 调用的异常
